9m LV Hot Dip Galvanized Octagonal Electric Steel Pole for Iraq
High-quality 9-meter low-voltage octagonal steel power pole with hot dip galvanized coating, specifically designed for electricity distribution in Iraq.
Product Specifications
| Specification | Details |
| Suit for | Electricity distribution |
| Shape | Conoid, Multi-pyramidal, Columniform, polygonal or conical |
| Material | Q345B/A572 (minimum yield strength ≥345N/mm²)
Q235B/A36 (minimum yield strength ≥235N/mm²)
Also available in Q460, ASTM573 GR65, GR50, SS400, SS490, ST52 |
| Tolerance of dimension | ±2% |
| Power | 10KV ~550KV |
| Safety Factor | Conducting wire: 8
Grounding wire: 8 |
| Design Load | 300~1000kg applied to 50cm from top pole |
| Surface Treatment | Hot dip galvanized (ASTM A123), color polyester powder, or client-specified standard |
| Joint of Poles | Insert mode, inner flange mode, face to face joint mode |
| Design Features | Earthquake resistant (8 grade), Wind speed: 160 km/h (30 m/s) |
| Material Strength | Minimum yield strength: 355 MPa
Minimum ultimate tensile strength: 490 MPa
Maximum ultimate tensile strength: 620 MPa |
| Standard | ISO 9001 |
| Production Process | Raw material test → Cutting → Molding/bending → Welding → Dimension verification → Flange welding → Hole drilling → Calibration → Deburring → Galvanization/coating → Recalibration → Threading → Packaging |
Material Description
- Poles are made from high-quality metal, molded into multi-row cone-shaped vertical steel bars with hot galvanized anti-corrosion treatment
- Light plate frame constructed from high-quality stainless steel
- Fastened with stainless steel bolts and nuts
Manufacturer Information
Jiangsu Milky Way Steel Poles Co., Ltd. was founded in 1991 and has grown into a leading company in power solutions. With over 30 years of experience, we provide a full range of services including design, manufacturing, equipment supply, and power investment. Our strong production and service network supports multiple business divisions. Our Group includes Jiangsu Milky Way Steel Poles Co., Ltd., Yixing Galaxy Power Equipment Co., Ltd., and Wuxi Power Equipment Co., Ltd., along with subsidiaries in Hong Kong and South Korea. We also have overseas service centers in Ecuador, Rwanda, and the Philippines. To date, we have served over 300 customers in more than 50 countries, delivering high-quality products and professional services across Europe, the Americas, Africa, and Southeast Asia.
